| Voltage (V): | 110/50-120/60 |
| Seal Material: | NBR |
| Orifice Main (inch): | 3/32 |
| Flow Factor Main (Cv): | 0.28 |
| Power (Watts): | 10 Watt (AC) |
| Coil Type: | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X |
| Maximum Pressure Differential (psi): | 125 psi (AC) |
| Product Series: | 7000 Series |
| Valve Type: | 3-Way |
| Function: | Normally Open, Pressure in Sleeve-Out Body |
| Port Size: | 1/4 inch |
| Input Voltage: | 110/50-120/60 |
| Body Material: | 430F Stainless |
| Seal Material: | NBR |
| Main Orifice Size: | 3/32 inch |
| Main Flow Coefficient: | 0.28 Cv |
| Power Consumption: | 10 Watt (AC) W |
| Coil Type: | 1/2" NPT Conduit, 18" Leads, Class F, NEMA 4X |
| Maximum Pressure Differential: | 125 psi (AC) psi |
| Additional Options: | Exhaust Adapter Nut |
| Number of Ports: | 3 |
| Actuation Type: | Direct Acting |
| Media: | General Purpose for Air, Liquids and Gases |
| Port Type: | NPT |
| Exhaust Orifice Size: | 3/32 inch |
| Exhaust Flow Coefficient: | 0.17 Cv |
| Orifice 2 Size: | n/a |
| Flow Coefficient 2: | n/a |
| Minimum Pressure Differential: | 0 psi |
| Minimum Fluid Temperature: | 0 °F |
| Maximum Fluid Temperature: | 185 °F |
| Coil Specifications Met: | NEMA 4X |
