Bội trơn Lubricator PARKER L606-08W/M8

Bội trơn Lubricator PARKER L606-08W/M8


Hãy trở thành người đầu tiên đánh giá sản phẩm này( 0)
Bội trơn Lubricator PARKER L606-08W/M8 được thiết kế gọn nhẹ. Bội trơn Lubricator PARKER L606-08W/M8 ứng dụng cho nhiều lĩnh vực  Product Specifications: Item Air Line Lubricator Adjustment Type Screwdriver Body Material Zinc Bowl Material Zinc Bowl Size 16 oz. Dome Polycarbonate Height 9.880" Knob Plastic …

Liên hệ

  • Mã sản phẩm:
  • L606-08W-M8
  • Đơn vị tính:
  • Cái
  • Tình trạng:
  • Nhận đặt hàng
  • Thương hiệu:
  • Parker Hannifin
  • Nhà cung cấp:
  • Parker US

Technical Specifications


Port Type: -- - NPT
Port Size: 08 - 1 Inch
Bowl Options: W - 16 oz. Metal Bowl with Sight Gauge
Options: Blank -None
Product Type: High-Flow Lubricator
Port Type: NPT | BSPP | 400
Port Size: 3/4" | 1" | 1-1/4" | 1-1/2"
Body Material: Zinc
Bowl Type: Aluminum
Seal Material: Nitrile

Operating Pressure: 0 to 300 (E Bowl Option) | 0 to 150 (G Bowl Option) | 0 to 250 (W bwol option) psig, 4.4 to 65.4 (E Bowl Option) |4.4 to 52 (G Bowl Option) | 4.4 to 65.4 (W Bowl Option) bar
Operating Temperature: +40° to +125° (G Bowl Option) | +40° to +150° (E and W Bowl Options) °F, 0° to +10.5° (G Bowl Option) | 0° to +17.2° (E and W Bowl Options) °C
Minimum Flow Rate: 1.5 SCFM
Maximum Flow Rate: 325 | 350 SCFM
Drain Option: Twist Drain
Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929  hoặc email phuc.dao@phucthinh-tech.com
Bội trơn Lubricator PARKER L606-08W/M8 được thiết kế gọn nhẹ. Bội trơn Lubricator PARKER L606-08W/M8 ứng dụng cho nhiều lĩnh vực

Product Specifications:

Item Air Line Lubricator
Adjustment Type Screwdriver
Body Material Zinc
Bowl Material Zinc
Bowl Size 16 oz.
Dome Polycarbonate
Height 9.880"
Knob Plastic
Length 4.970"
Material Zinc
Max. Flow 350 cfm
Max. Pressure 250 psi
Max. Temp. 150 F
NPT 1"
Oil Capacity 16 oz.
Overall Height 9.880"
Overall Length 4.970"
Overall Width 4.970"
Pipe Runs (Ft.) 25
Pipe Size 1" NPT
Width 4.970"

Vui lòng liên hệ để được báo giá tốt nhất cho Bội trơn Lubricator PARKER L606-08W/M8
