121G2520-852023-483541T1
121G2520-852023-483541T1
| Maximum Operating Pressure: | 30 bar |
| Actuation Type: | Direct Operated |
| Coil Specifications Met: | CE - EAC |
| Port Size: | 1/2" G |
| ATEX Specifications Met: | - |
| Function: | Normally Closed |
| Seal Material: | FKM |
| Flow Coefficient 1: | 25 l/min |
| Electrical Connection: | Screw Terminals |
| Specifications Met: | DIN-EN-ISO 23553-1 (2009-10) approved for oil burners |
| Power Supply Voltage: | 230V 50Hz - 240V 60Hz |
| Minimum Fluid Temperature: | 0 °C |
| Valve Type: | 2/2-Way |
| Port Type: | Pipe Mounting |
| Media: | Oils |
| Seat Material: | Brass |
| Orifice Size: | 14 mm |
| Flow Coefficient 2: | 1.5 m3/hour |
| Minimum Operating Pressure: | 0 bar |
| Maximum Fluid Temperature: | 160 °C |
| Coil Power Consumption: | 20 W |
| Coil Temperature Range: | -40 to 50 °C |
| Insulation Class: | H (180°C)     |
121G2520-852023-483541T1
