| Configuration: | Normally Closed |
| Seal Material: | FKM |
| Maximum Operating Pressure Differential (psig): | 375 |
| Voltage: | 120/60, 110/50 |
| Body Material: | 303 Stainless Steel |
| Port Size (inch): | 1/4 NPT |
| Minimum Pressure Differential (psi): | 0 |
| Coil Type: | 1/2" NPT Conduit w/ Leads (Incl. Ground Lead) |
| Orifice Size (inch): | 1/8 |
| Function: | 2-Way |
| Function: | 2-Way |
| Configuration: | Normally Closed, All Ports in Body |
| Port Size: | 1/4 NPT inch |
| Actuation Type: | Direct Acting |
| Minimum Pressure Differential: | 0 psi |
| Maximum Pressure Differential: | 375 psig |
| Body Material: | 303 Stainless Steel |
| Seal Material: | FKM |
| Maximum Fluid Temperature: | 185 °F |
| Maximum Ambient Temperature: | 150 °F |
| Orifice Size: | 1/8 inch |
| Main Flow Coefficient: | 0.29 Cv |
| Exhaust Flow Coefficient: | N/A |
| Input Voltage: | 120/60, 110/50 |
| Power Consumption: | 10 W |
| Coil Specifications Met: | IP69 |
| Installation: | IOM7220 |
| Preventive Maintenance Kit: | 7R003 |
| Specifications Met: | UL, CSA Listed Safety Shutoff |
