DOWNLOAD CATALOGUE Parker_Pneumatic_PS1_Modular_Interface_Valve_Catalogue_PDE2626TCUK
Description Electrical: 1SPDT Contact 5A / 250V
Description Pneumatic: 20PSI Fixed Switching Pressure
Adjustable Trip Pressure: 30 to 75 PSI (2 to 5 bar)
Air Quality: Standard Shop Air, Lubricated or Dry, 40 μm Filtration
Degree of Protection: IP 40
Electrical Connections: Screw Terminals
Fixed Trip Pressure: ≥20 PSI (1.3 bar)
Function: SPDT Contacts
Insulation Voltage Rating: 250V AC or DC
Materials: Body - Polyamide|Poppet - Polyurethane|Seals - Nitrile (Buna N)
Maximum Operating Frequency: 10 Hz
Mounting: Inline or 35 mm DIN Rail
Nominal Current Rating: 5 A
Number of Operations with Dry Air at 90 PSI and 70°F – Frequency 1 Hz: 10 Million
Operating Positions: All Positions
Operating Pressure: 115 PSIG Max. (8 bar)
Ports: 5/32" Instant for Semi- Rigid Nylon or Polyurethane Tube
Response Time: 2 to 3 msec
Temperature Operating: 32°F to 122°F (0°C to +50°C)
Temperature Storage: -22°F to 140°F (-30°C to +60°C) Liên hệ trực tiếp đến chúng tôi theo Hotline/ zalo 0937 664 929 hoặc email phuc.dao@phucthinh-tech.com
Working pressure Max 10 bar Working temperature -15 °C to +60 °C Minimum actuating pressure, non adjustable ≤1,3 bar Minimum actuating pressure, adjustable 2 to 5 bar Operating frequensy Max 10 Hz • Effective detection for preventing hazardous risks linked with equipments operating at to low pressure • Manual override • Easy clip on DIN rail mounting • Fixed or adjustable threshold versions • Recessed Electrical Terminals Type Symbol Electrical Pneumatic Override Weight (g) Order code characteristics characteristics Pressure switch Fixed operating Manual 50 PS1-P1081 1 CO contact threshold override 5 A/250 V < 1,3 bar Adjustable ope- Manual 50 PS1-P1091 rating threshold override 2 to 5 bar Nominal isolation voltage 660 V AC or DC Nominal therminal current 10 A Operating voltage 250 V Pending current 5 A Protection level IP 40 According Power switches (inductive lead)
